PC2/PC2X Disassembly/Assembly
Top Enclosure
4-7
Top Enclosure
The top enclosure includes five boards: Connector, Front Panel, LCD, Slider, and Engine. The
Right and Left Enclosure Support Walls are also included on the top enclosure. Figure 4-5 shows
the placement of the enclosure support walls. Figure 4-6 shows the placement of the boards.
Figure 4-5 Top enclosure, enclosure support walls
Figure 4-6 Top enclosure, board locations
Left Enclosure Support Wall
Right Enclosure Support Wall
LCD Board
Front Panel Board
Engine Board
Slider Board
Connector Board

Kurzweil PC2 Series Specifications

General

Polyphony	64 voices
Sound Engine	VAST (Variable Architecture Synthesis Technology)
MIDI	In, Out, Thru
Multitimbral	16 parts
Velocity Sensitivity	Yes
Aftertouch	Yes
Year Released	1999
Display	LCD
Controllers	Pitch wheel, modulation wheel
Inputs	Sustain pedal, expression pedal
Memory	128 setups
Keyboard	76-note, semi-weighted
Outputs	Stereo outputs, headphone output
