Kurzweil PC2 Series User Manual

4-28
PC2/PC2X Disassembly/Assembly
PC2X Keyboard Assembly
Natural/White Key
Figure 4-17 Natural/white key, 88-note keyboard
Figure 4-18 Sharp/black key, 88-note keyboard
Natural/White Keys
1. Remove the silver key spring located at the rear of the key. You will notice that the bottom
of the spring is secured to the keyboard chassis by a hook.
You can remove the spring by inserting a dowel (3mm diameter) into the spring, and
pushing down on it slightly. Then pull the top of the dowel toward the front of the
keyboard. This will unhook the spring from the keyboard chassis.
Strikes the front and rear key
contact on key depression
Mounts through the
keyboard chassis
Key spring
location
Pivot
location
Hooks under the front
of the keyboard chassis
Strikes the front and rear key
contact on key depression
Mounts through the
keyboard chassis
Key spring
location
Pivot
location
Hooks under the front
of the keyboard chassis

Kurzweil PC2 Series Specifications

General

Polyphony	64 voices
Sound Engine	VAST (Variable Architecture Synthesis Technology)
MIDI	In, Out, Thru
Multitimbral	16 parts
Velocity Sensitivity	Yes
Aftertouch	Yes
Year Released	1999
Display	LCD
Controllers	Pitch wheel, modulation wheel
Inputs	Sustain pedal, expression pedal
Memory	128 setups
Keyboard	76-note, semi-weighted
Outputs	Stereo outputs, headphone output
