Kurzweil PC2 Series User Manual

Parts Lists
PC2R/PC2/PC2X
6-3
PC2R/PC2/PC2X
Engine Board, N012300051
Part No. Description Qty. Reference Designation
N035040201 BATTERY HOLDER TOSHIBA (BV-32) PC-88 1 J411
N041010401 SHUNTS JUMPER 2mm DIGI-KEY SPE1302-ND 1 @JP1
N041021264 SOCKET SIMM 22.5D TIN 64P LEFT METAL 2 J409, 410
N041025308 HEADER .156” SP 8P (09-65-2088) 1 J402
N041030040 HEADER 2mm SQR 3P R/A SAMTEC 1 JP1
N041030124 HEADER DUAL 2.0mm 24P MOLEX 87089-2416 1 J408
N041030150 HEADER DUAL 0.1" SQR 50POS DIGIKEY 1 J404
N041031210 CONN .1" SP DUAL ROW 14P (057-014-153) 1 J406
N041032305 CONN WIRE TRAP 2.00mmSP 5P (52147-0510) 1 J412
N041032310 CONN WIRE TRAP 2.00mmSP 10P (52147-1010) 1 J403
N041034002 HEADER .098" SP 2P (22-03-5025) 1 J405
N042005422 JUMPER WIRE 2.5MM 1 JP2 PINS 1 & 2
N051102103 RELAY 5V DPDT (G6H-2-DC5) 2 RY1-2
N064003502 IC LINEAR +5V LM78M05 500mA TO-220 1 VR1
N051064004 RES TF 47Ω 5% 1/16W 0603 T&R 4 R1, 26, 27, 39
N051064010 RES TF 100Ω 5% 1/16W 0603 T&R 1 R38
N051064011 RES TF 110Ω 5% 1/16W 0603 T&R 1 R28
N051064015 RES TF 1.5KΩ 5% 1/16W 0603 2 R64, 65
N051064025 RES TF 330Ω 5% 1/16W 0603 1 R32
N051064100 RES TF 1KΩ 5% 1/16W 0603 T&R 4 R5, 8, 34, 68
N051064109 RES TF 1MΩ 5% 1/16W 0603 T&R 2 R15, 16
N051064110 RES TF 10KΩ 5% 1/16W 0603 T&R 10 R7, 14, 17-18, 23-25, 29, 36-37
N051064130 RES TF 1.3KΩ 5% 1/16W 0603 T&R 1 R4
N051064220 RES TF 2.2KΩ 5% 1/16W 0603 T& 2 R6, 9
N051064470 RES TF 4.7KΩ 5% 1/16W 0603 T&R 3 R2, 10, 30
N051064472 RES TF 470Ω 5% 1/16W 0603 2 R31, 33
N051064820 RES TF 820Ω 5% 1/16W 0603 1 R3
N051066124 RES TF 1.24KΩ 1% 1/16W 0603 4 R60, 61, 66, 67
N051066453 RES TF 453Ω 1% 1/16W 0603 4 R56, 57, 62, 63
N051066464 RES TF 464Ω 1% 1/16W 0603 4 R48-51
N051066475 RES TF 475Ω 1% 1/16W 0603 4 R52-55
N051066487 RES TF 487Ω 1% 1/16W 0603 4 R40-43
N051066499 RES TF 499Ω 1% 1/16W 0603 4 R44-47
N051100010 RES NET QUAD ISO 10KΩ 5% 1/16W 11 RP1-4, 6-12
N051100047 RES NET QUAD ISO 47Ω 5% 1/16W 9 RP13-21
N051101701 RES TF 36Ω 5% 1/8W 1206 1 R35
N051101706 RES CF 47Ω 5% 1/8W 1206 1 R70
N051130082 RES TF 8.2Ω 5% 1/4W 1210 1 R13
N051130220 RES TF 220Ω 5% 1/4W 1210 2 R19, 21
N051130330 RES TF 330Ω 5% 1/4W 1210 2 R20, 22
N052007006 CAP CER NPO 6.8PF 50V 5% 1206 2 C11, 13

Kurzweil PC2 Series Specifications

General

Polyphony	64 voices
Sound Engine	VAST (Variable Architecture Synthesis Technology)
MIDI	In, Out, Thru
Multitimbral	16 parts
Velocity Sensitivity	Yes
Aftertouch	Yes
Year Released	1999
Display	LCD
Controllers	Pitch wheel, modulation wheel
Inputs	Sustain pedal, expression pedal
Memory	128 setups
Keyboard	76-note, semi-weighted
Outputs	Stereo outputs, headphone output
