Kurzweil PC2 Series - Keyboard Assembly, N215040311

6-10
Parts Lists
PC2
Keyboard Assembly, N215040311
N032038813 CLAMP PCB PC2/X 5
N032038814 BRACKET CLAMPING ENCLOSURE TOP PC2/X 2
N032038815 BRACKET LOCKING ENDCAP PC2/X 2
N032038950 SPACER (BLK) 2
N032059011 PLATE COVER PCB PC2/X 1
N035020711 KNOB ENCODER 52 1
N035026511 LCD DISPLAY LENS PC-88 1
N039004322 CABLE MOUNT BASE (DAMD-10) 9
N125223408 TAPPING SCREW-2 BH 3X8 BLK (PLASTIC) 4
N125223410 TAPPING SCREW-2 BH 3X10 AN (PLASTIC) 2
N032033521 TOP COVER PC2 1
N039040004 BUMPON 3M 4
N052001022 ADAPTER 1
N035027013 CHECK PITCH & MOD WHEEL 1
N032033713 ENDCAP LEFT 1
N032033813 ENDCAP RIGHT 1
N125223408 TAPPING SCREW-2 BH 3X8 BLK (PLASTIC) 14 FOR ENDCAPS
N215040311 KEYBOARD TP-8R AFT STRIP 76 NOTE 1
Part No. Description Qty. Reference Designation
PCB KEY CONTACT LOW
PCB KEY CONTACT HIGH
KEY CONTACT STRIP (12 NOTE)
BRACKET ROD/KEY WEIGHT SUPPORT 12 PO
KEY PIVOT
BRACKET ROD/KEY WEIGHT SUPPORT 4 POS
KEY NATURAL A
KEY NATURAL B
KEY NATURAL C
KEY NATURAL D
KEY NATURAL E
KEY NATURAL F
KEY NATURAL G
KEY NATURAL LOW A
KEY NATURAL HIGH C
KEY SHARP
KEY WEIGHT NATURAL
KEY WEIGHT SHARP
FELT RED
AFTER TOUCH STRIP
Part No. Description Qty. Reference Designation
