Kurzweil PC2 Series User Manual

Chapter 6
Parts Lists
Introduction
The parts lists included in this chapter cover all models of the PC2 series. Some printed circuit
boards and assemblies are used in more than one model. Therefore, the parts lists on the
following pages are listed under these headings:
The following two tables list the printed circuit boards and assemblies by model.
Note: The PC2 and PC2X have been combined as these two models share most printed circuit
boards and assemblies in common. The exceptions are the parts lists for the Final and Keyboard
Assemblies.
PC2/PC2X Printed Circuit Boards and Assemblies
PC2R/PC2/PC2X All Models
PC2/PC2X Keyboard Models
PC2R Rack Model
Part No. Description Page
N012000150 Final Assembly, PC2 page 6-9
N012000151 Final Assembly, PC2X page 6-11
N012103800 LCD Board page 6-8
N012300051 Engine Board page 6-3
N012300053 Pitch & Mod Wheel Assembly page 6-8
N012300061 Connector Board page 6-6
N012400051 Slider Board page 6-9
N012400052 Front Panel Board page 6-5
N215040311 Keyboard TP-8R AFT 76 Note page 6-10
N215040413 Keyboard TP-10MDF AFT 88 Note page 6-12

Kurzweil PC2 Series Specifications

General

Polyphony	64 voices
Sound Engine	VAST (Variable Architecture Synthesis Technology)
MIDI	In, Out, Thru
Multitimbral	16 parts
Velocity Sensitivity	Yes
Aftertouch	Yes
Year Released	1999
Display	LCD
Controllers	Pitch wheel, modulation wheel
Inputs	Sustain pedal, expression pedal
Memory	128 setups
Keyboard	76-note, semi-weighted
Outputs	Stereo outputs, headphone output
