Kurzweil PC2 Series - PC2 R Printed Circuit Boards and Assemblies

6-2
Parts Lists
Introduction
PC2R Printed Circuit Boards and Assemblies
Part No. Description Page
N012000153 Final Assembly page 6-16
N012103802 LCD Board page 6-15
N012300040 Connector Board page 6-13
N012300051 Engine Board page 6-3
N012300070 Front Panel Assembly page 6-14
N012300080 Left Front Panel Board page 6-14
N012300090 Right Front Panel Board page 6-15
N012700019 Headphone/Volume/Power Switch Board page 6-15
