PC2/PC2X Disassembly/Assembly
Opening the PC2/PC2X
Opening the PC2/PC2X
PC2 Bottom
Refer to Figure 4-1. Arrows indicate the locations of the enclosure support wall, endcap and rear
panel screws.
Figure 4-1 PC2 bottom enclosure
Caution: Do not remove the endcap or rear panel screws at this point of the procedure.
1. Tilt the PC2 up and remove the eight enclosure support wall screws.
2. Place the unit flat on your work surface.
3. Move the unit so that the rear panel portion of the unit hangs over the edge of your work
surface. This gives you access to the seven screws that secure the rear panel portion of the
top enclosure to the bottom enclosure. Remove the seven screws.
Note: Two of the rear panel screws also secure the rear panel portion of the access panel.
It is not necessary to remove the five remaining access panel screws.
4. Slide the unit back onto the work surface.
Enclosure support wall screws
Rear panel screws
Rear panel
Keyboard
Endcap screws
Endcap screws
* *
*Endcap locking bracket screws
Access panel
