Kurzweil PC2 Series User Manual

Parts Lists
PC2R
6-13
PC2R
Connector Board, N01230004
Part No. Description Qty. Reference Designation
RES TF 7.5KΩ 5% 1/8W 1206 1 R19
N041006503 CONN PWR JACK 4P W/SHIELD UNITOP 1 J321
N041021903 JACK PHONE RCA TYPE TA PCMT 1 J300
N041025308 HEADER .156" SP 8P (09-65-2088) 1 J301
N041030326 HEADER .1" SP DUAL ROW 26P (057-026-153) 1 J304
N041031104 JACK 1/4" STEREO (EPJ-BBB-P) BELTON 2 J311-312
N041032305 CONN WIRE TRAP 2.00mm SP 5P (52147-0510) 1 J302
N041032310 CONN WIRE TRAP 2.00mmSP 10P (52147-1010) 1 J303
N041034010 HEADER .098" SP 10P (22-03-5105) 1 J322
N041034031 CONN MIDI TRIPLE R/A PCMT (YKF51-5046) 1 J320
N043010510 SWITCH SLIDER R/A 2.5mmSP SPDT 1 S1
N051064005 RES TF 56Ω 5% 1/16W 0603 T&R 4 R93, 96, 99, 102
N051064011 RES TF 110Ω 5% 1/16W 0603 T&R 6 R17, 20, 94-95, 97-98
N051064016 RES TF 1.6KΩ 5% 1/16W 0603 1 R118
N051064022 RES TF 220Ω 5% 1/16W 0603 2 R100-101
N051064110 RES TF 10Ω 5% 1/16W 0603 T&R 13 R1-3, 12, 14, 24, 108-109, 121, 126, 128, 144, 147
N051100010 RES NET QUAD ISO 10KΩ 5% 1/16W 4 RP9-12
N051100011 RES NET QUAD ISO 100Ω 5% 1/16W 3 RP6-8
N051101706 RES CF 47Ω 5% 1/8W 1206 2 R134, 137
N051101708 RES CF 56Ω 5% 1/8W 1206 2 R4-5
N051101721 RES CF 270Ω 5% 1/8W 1206 1 R6
N051101724 RES 470 5% THICK FILM 1206 2 R18, 117
N051101730 RES CF 1.0KΩ 5% 1/8W 1206 2 R120, 148
N051101734 RES TF 1.5KΩ 5% 1/8W 1206 1 R22
N051101780 RES CF 100KΩ 5% 1/8W 1206 1 R15
N051101790 RES CF 1.0MΩ 5% 1/8W 1206 3 R11, 16, 119
N051102103 RELAY 5V DPDT (G6H-2-DC5) 1 RY1
N051103151 RES TF 15.00KΩ 1% 1/8W 1206 8 R122-123, 132-133, 135-136, 138, 142
N051120030 RES TF 3.0KΩ 5% 1/8W 1206 3 R106, 127, 129
N051120056 RES TF 5.6KΩ 5% 1/8W 1206 1 R8
N051125201 RES TF 200Ω 5% 1/4W 1210 4 R124, 130, 139, 141
N052001204 CAP CER MONO Z5U 0.1UF 50V 20% 3AX 3 C1-3
N052001223 CAP CER MONO 0.22UF 50V 20% AX 1 C39
N052001711 CAP ELECT 100UF 25V 20% RAD 4 C28, 34, 36, 37
N052001712 CAP ELECT 1000UF 25V RAD 1 C30
N052002412 CAP ELECT 470UF 25V 20% .2SP 1 C31
N052007401 CAP CER NPO 100PF 50V 5% 1206 2 C46, 55
N052007503 CAP CER X7R 0.1UF 50V 10% 1206 16 C29, 32-33, 35, 38, 41-42, 44-45, 49-54, 56
N052007810 CAP CER X7R 1000PF 50V 10% 0603 10 C17-22, 25-27, 47
N052007833 CAP CER NPO 33PF 50V 5% 0603 2 C4-5
N052901602 CAP ELECT GP 0.197" SP RAD 1000UF 16V 20% 1 C40

Kurzweil PC2 Series Specifications

General

Polyphony	64 voices
Sound Engine	VAST (Variable Architecture Synthesis Technology)
MIDI	In, Out, Thru
Multitimbral	16 parts
Velocity Sensitivity	Yes
Aftertouch	Yes
Year Released	1999
Display	LCD
Controllers	Pitch wheel, modulation wheel
Inputs	Sustain pedal, expression pedal
Memory	128 setups
Keyboard	76-note, semi-weighted
Outputs	Stereo outputs, headphone output
