Kurzweil PC2 Series User Manual

6-6
Parts Lists
PC2/PC2X
Connector Board, N012300061
N051100157 RES CF 10KΩ 5% 1/8W 18 R9-26
N052001204 CAP CER MONO Z5U .1UF 50V 20% .3AX 3 C2-4
N054000801 TRANSISTOR PN2222 TO-92 7 Q1-7
N054001201 TRANSISTOR PNP KTA1271(KSA643CY) TO-9 10 Q8-17
N061000301 IC LOGIC 74LS145 DIP16-300 1 U2
N061014001 IC LOGIC 74HC541 DIP20 1 U1
N061020501 IC LOGIC 74HC373 DIP20 1 U3
N252003102 CAP ELECT ECE-BOJU471 470UF 6.3V VERT AX 2 C1, 6
Part No. Description Qty. Reference Designation
RES TF 7.5KΩ 5% 1/8W 1206 1 R19
N025224508 TAPPING SCREW-2 BH 3.5X8 WHITE W/WASHER 3
N025323308 MACHINE SCREW BH M3X8 BLK 1
N032038811 BRACKET SUPPORT I/O PCB PC2/X 1
N032038816 BRACKET SUPPORT POWER JACK PC2/X 1
N032064801 EXTRUSION HEAT TRANSFER 1
N041006503 CONN PWR JACK 4P W/SHIELD UNITOP 1 J321
N041021903 JACK PHONE RCA TYPE TA PCMT 1 J300
N041025308 HEADER .156” SP 8P (09-65-2088) 1 J301
N041030033 MODULAR JACK 6P R/A AMP 555163-1 1 J316
N041030310 CONN MIDI JACK 3-GANG YKF 51-5041(JALCO) 1 J320
N041031220 HEADER .1” SP DUAL ROW 20P (057-020-153) 3 J304, 306, 307
N041032305 CONN WIRE TRAP 2.00mmSP 5P (52147-0510) 1 J302
N041032306 CONN WIRE TRAP 2.00mmSP 6P (52147-0610) 1 J308
N041032307 CONN WIRE TRAP 2.00mmSP 7P (52147-0710) 1 J305
N041032310 CONN WIRE TRAP 2.00mmSP 10P (52147-1010) 1 J303
N041034401 PHONE JACK MONO 1/4” RA49C-12A MONO 3 J317-319
N041034411 CONN STEREO 1/8” W/SWITCH UNITOP 1 J315
N041034501 PHONE JACK STEREO 1/4” RA49C-14B 5 J310-314
N043003702 SWITCH POWER DPDT NKK M2022TXW30-DA 1 S2
N043010510 SWITCH SLIDER R/A 2.5mmSP SPDT 1 S1
N051064005 RES TF 56Ω 5% 1/16W 0603 4 R93, 96, 99, 102
N051064011 RES TF 110Ω 5% 1/16W 0603 12 R17, 20, 65, 68, 69, 73-75, 94, 95, 97, 98
N051064015 RES TF 1.5KΩ 5% 1/16W 0603 1 R22
N051064022 RES TF 220Ω 5% 1/16W 0603 4 R100, 101, 126, 128
N051064110 RES TF 10KΩ 5% 1/16W 0603 21 R1-3, 9, 10, 12-14, 24, 70, 77, 84-86, 108, 109, 121, 144, 146, 147, 149
N051064150 RES TF 150Ω 5% 1/16W 0603 1 R81
N051064470 RES TF 470Ω 5% 1/16W 0603 1 R118
N051100010
RES NET QUAD ISO 10KΩ 5% 1/16W
3.2mmX1.6mm
5 RP9-13
N051100011 RES NET QUAD ISO 100Ω 5% 1/16W 8 RP1-8
N051101706 RES CF 47Ω 5% 1/8W 1206 2 R134, 137
N051101708 RES TF 56Ω 5% 1/8W 1206 2 R4, 5
Part No. Description Qty. Reference Designation

Kurzweil PC2 Series Specifications

General

Polyphony	64 voices
Sound Engine	VAST (Variable Architecture Synthesis Technology)
MIDI	In, Out, Thru
Multitimbral	16 parts
Velocity Sensitivity	Yes
Aftertouch	Yes
Year Released	1999
Display	LCD
Controllers	Pitch wheel, modulation wheel
Inputs	Sustain pedal, expression pedal
Memory	128 setups
Keyboard	76-note, semi-weighted
Outputs	Stereo outputs, headphone output
