Parts Lists
PC2
6-9
Slider Board, N012400051
PC2
Final Assembly, N012000150
Part No. Description Qty. Reference Designation
N035026158 BUTTON LG W/LED (ZONE1,3,4) PC2 4
N035026321 SLIDER KNOB PC-88 5
N035026411 SLIDER BEZEL PC-88 5
N039000701 SLIDE VOLUME FELT 0.3TX12X70 5
N041032307 CONN WIRE TRAP 2.00mmSP 7P (52147-0710) 1 J101
N041032308 CONN WIRE TRAP 2.00mmSP 8P (52147-0810) 1 J102
N043003703 SW TACT SPST 6mmX6mm 160GF ALPS SKHWAC 4 S1-4
N045010610 LED MINI RED/GREEN DIFUSSED T1 DKL-30RGM 4 D1-4
N051101502 SLIDER VOLUME SINGLE 10KB-LIN 45mm 5 R1-5
N053000801 DIODE 1N4148 DO-35 4 D5-8
Part No. Description Qty. Reference Designation
E207407181 DOUBLE SIDE TAPE 3M (5MMX50M) #467 0.01
N013030951 CABLE TIE 13
N013041601 CABLE SLIDER TO FRONT PANEL 8P PC2/X 1
N013041701 CABLE SLIDER TO CONN BD 7P PC2/X 1
N013041801 CABLE ENGINE TO CONN BD 10P PC2/X 1
N013041901 CABLE ENGINE TO CONN BD 5P PC2/X 1
N013042001 CABLE WHEEL TO CONN BD 6P PC2/X 1
N013042101 CABLE BUTTON BD TO FRONT PANEL 5P PC2/X 1
N013042201 CABLE ENGINE TO CONN BD POWER PC2/X 1
N013042301 CABLE KEYBOARD BASS & TREBLE PC2/X 1
N013042302 CABLE KEYBOARD BASS PC2 1
N013042401 CABLE FRONT PANEL TO CONN BD PC2/X 1
N015048232 FELT 2TX20X1200 BLK KEYBOARD K2500/S 1
N022002703 SPACER PUSH LOCKING 8.0MM TALL 4
N022003714 CABLE CLAMP 14P 1
N022003720 CABLE CLAMP 20P 4
N025153512 TAPPING SCREW-1 TH 3.5X12 BLK 8
N025153520 TAPPING SCREW-1 TH 3.5X20 BLK 16
N025224508 TAPPING SCREW-2 BH 3.5X8 WHITE W/WASHER 35
N025323408 MACHINE SCREW BH M4X8 BLK 35
N025323410 MACHINE SCREW BH M4X10 BLK 4
N025323414 MACHINE SCREW BH 4X14 BLK 2
N025328310 MACHINE SCREW BH 3X10 BLK W/WASHER 4
N032033632 BOTTOM PC2 1
N032037732 LEFT SUPPORT WALL PC2/X 1
N032037822 RIGHT SUPPORT WALL PC2/X 1
To Next Page
