Introduction
PC2/PC2X
1-5
Figure 1-5 Sound/Setup Select and Effects and Reverb sections
Sound/Setup Select—Three groups of buttons are included in this section. Use the buttons in
the first group to select one of the three performance modes: Internal Voices, MIDI Setups, or
KB3 Mode. The second group, Previous Group and Next Group, is for use in the Internal Voices
and MIDI Setups modes only. Depending on which mode you’re in, they select the previous or
next group of programs or setups. Use the buttons in the third group, labelled 1–16, to select a
category of Internal Voice programs or MIDI setups. In KB3 Mode, use these buttons to select
one of the 16 KB3 programs.
Effects and Reverb—Use the buttons in this section to select from two blocks of effects to apply
effects and reverb to programs and setups.
Figure 1-6 Data Entry section
Data Entry—This section contains the Alpha Wheel, Minus (-) and Plus (+) buttons, and the
Alphanumeric keypad. Use the Alpha Wheel or the Minus (-) and Plus (+) buttons to increase or
decrease a value. Use the buttons in the Alphanumeric keypad to enter text, numbers, spaces,
etc. This section also includes the Cancel (No) and Enter (Yes) buttons.
Mod/Pitch Wheel Assembly (not shown)—Use the two wheels to vary modulation and pitch.
Also included on the assembly is the SW4 and SW5 switches for use in the Internal Voices and
MIDI Setups modes.
Demo
12345678
910111213141516
Internal
Voices
Previous
Group
Next
Group VoicesStrings
Piano 2Piano 1
Guitar
E Piano 1
Bass Drums
E Piano 2
Percussion
Pop Keys Clavier Organ
Synths
Brass
Pads
FX-A Select Wet / Dry
FX-B Select FX Mode
Mute A
Mute B
Sound / Setup Select Effects and Reverb
KB3
Mode
MIDI
Setups
123
456
789
+ / - 0 Clear
Cancel Enter
Data Entry
UPPER / lower 0 - 9 Space
No Yes
S T U V W X Y Z
J K L M N O P Q R
A B C D E F G H I
