PC2/PC2X Disassembly/Assembly
Opening the PC2/PC2X
4-5
Figure 4-4 Top cover and bottom enclosure
Warning: Be sure to have your work surface prepared. This includes
placing foam blocks behind the unit. When the top enclosure is removed,
place it on the foam blocks to avoid damaging the Alpha Wheel, control
panel buttons, and sliders. The following procedure requires enough room
behind the rear of the unit to place the top enclosure face down on your
work surface.
6. Grip each end of the top enclosure and rotate it back approximately two inches. This
separates the bottom edges of the top enclosure and bottom enclosure.
7. Lift the top enclosure straight up.
8. Turn the top enclosure over and place it face down onto your work surface.
Caution: Table 4-1 lists the cables, by board location, from the top enclosure to the assembly
they connect to on the bottom enclosure. You do not need to disconnect these cables.
Top cover Assembly Bottom Enclosure
Connector Board Keyboard Assembly
Connector Board Keyboard Assembly
FP Board Button Board/Wheel Assembly
Connector Board Mod Wheel Assembly
Table 4-1 Top cover and bottom enclosure cables
Rear panel screw locations
Lip
