Kyocera ECOSYS P8060cdn - Replacing Staples (4,000-Sheet Finisher)

To Next Page

To Previous Page

10-9

Troubleshooting > Regular Maintenance

Install the Staple Cartridge Holder.

Close the cover.

Replacing Staples (4,000-Sheet Finisher)

When the Staple Unit runs out of staples, the following messages will be displayed. The staple cartridge holder need to

be replenished with staples.

"Staple is empty."

Open the finisher front cover 1.

NOTE

If the Staple Unit runs out of staples, contact your dealer or service representative.
