Kyocera ECOSYS P8060cdn - Part Names (with Optional Equipments Attached)

To Next Page

To Previous Page

2-5

Installing and Setting up the Machine > Part Names (With Optional Equipments Attached)

Part Names (With Optional Equipments

Attached)

1 Tray 1 to 7 (tray 1 is the top tray)

2 Tray A

3 Tray B

4 Job Separator Tray

5 Folding Tray

Optional Equipment (page 11-2)

6 Cassette 3

7 Cassette 4

8 Cassette 5

9 Finisher Tray

10 Control Section of the Finisher

Manual Staple (page 5-30)
