Kyocera ECOSYS P8060cdn - Part Names (Machine Exterior)

To Next Page

To Previous Page

2-2

Installing and Setting up the Machine > Part Names (Machine Exterior)

Part Names (Machine Exterior)

1 Operation Panel

2 Power Switch

3 Waste Toner Box Cover

4 Cassette 1

5 Cassette 2

6 Handles

7 Main Power Switch

8 USB Memory Slot

9 Paper Stopper

10 Main Tray

11 Front Cover

12 First Printed Side Support
