11-2

Appendix > Optional Equipment

Optional Equipment

Overview of Optional Equipment

The following optional equipment is available for the machine.

* If the following option is installed, toppling prevention kit must be installed: PF-7100, PF-7110

(1) MT-730(B)

(3) DF-7120 (4) BF-730 (5) PF-7100* (6) PF-7110*

(7) PF-7120

(10) PH-7A, PH-7C,

PH-7D

(2) DF-7110

(8) Banner Guide 10

(9) JS-7100
