Kyocera ECOSYS P8060cdn - Clearing a Staple Jam of the Folding Unit

To Next Page

To Previous Page

10-92

Troubleshooting > Clearing a Staple Jam

Return the cover to the original position.

Clearing a Staple Jam of the Folding Unit

Open the finisher front cover 1 and 2.

Remove paper from inside the finisher.
