Kyocera ECOSYS P8060cdn

To Next Page

To Previous Page

10-91

Troubleshooting > Clearing a Staple Jam

Return the conveyor guide (D4) to the original position.

Remove the Staple Cartridge Holder (A).

Remove the jammed staple.

Install the Staple Cartridge Holder (A).
