Kyocera ECOSYS P8060cdn - Connecting Cables; Connecting LAN Cable

To Next Page

To Previous Page

2-7

Installing and Setting up the Machine > Connecting Cables

Connecting Cables

Connecting LAN Cable

Connect the cable to the machine.

1 Connect the LAN cable to the network interface connector.

2 Connect the other end of the cable to the hub.

Power on the machine and configure the network.

Network Setup (page 2-25)
