Kyocera FS-C8520MFP - Page 198

2MY/2MZ
1-4-10
0150 Backup memory read/write
error (engine PWB)
Detecting engine PWB
EEPROM communication
error.
The engine PWB
EEPROM was
improperly
installed.
Check the EEPROM is properly installed
and remedy if necessary.
Defective engine
PWB.
Replace the engine PWB and check for cor-
rect operation (see page 1-5-32).
Defective
EEPROM.
Contact the Service Administrative Division.
0160 Backup memory data error
(engine PWB)
Defective flash
memory.
Replace the engine PWB and check for cor-
rect operation (see page 1-5-32).
Defective engine
PWB.
0170 Billing counting error
A checksum error is detected
in the main and engine
backup memories for the bill-
ing counters.
Data in the
EEPROM .
Contact the Service Administrative Division.
Defective PWB. Replace the main PWB or the engine PWB
and check for correct operation
(see page 1-5-31, 1-5-32).
0180 Machine number mismatch
Machine number of main and
engine does not match.
Data in the
EEPROM .
Contact the Service Administrative Division.
0320 I/O CPU communication
error
A communication error is
detected 10 times in succes-
sion.
Defective PWB. Replace the main PWB or the engine PWB
and check for correct operation.
(see page 1-5-31,1-5-32)
0630 DMA error
DMA transmission of image
data does not complete within
the specified period of time.
Poor contact in the
connector termi-
nals.
Check the connection the signal cable for
CIS and the main PWB, and the continuity
across the connector terminals. Repair or
replace if necessary.
Defective main
PWB.
Replace the main PWB and check for cor-
rect operation (see page 1-5-31).
0800 Image processing error
The JAM100 fee counter is
continuously generated.
Defective main
PWB.
Replace the main PWB and check for cor-
rect operation (see page 1-5-31).
0830 FAX control PWB flash pro-
gram area checksum error
A checksum error occurred
with the program of the FAX
control PWB.
Defective FAX soft-
ware.
Install the fax software.
Defective FAX con-
trol PWB.
Replace the FAX control PWB.
Code Contents Causes
Check procedures/
corrective measures
