2MY/2MZ

2-1-10

Figure 2-1-13 Scanner unit block diagram

CCD


sensor

MPWB

CCDPWB

YC113-7

CCD_SH

CCDCLK1

OS1(B)

SCL

SDA

FAIL

OS2(G)

OS3(R)

YC113-13

YC113-15

YC112-8

YC112-9

YC112-10

YC113-17

YC113-19

EL

ISUM

HPS

Scanner unit

Lens

Mirrer

Image scaner unit (ISU)

Original

Platen

YC105

LEDPWB

YC26

EPWB

YC17-7

SCA_HP

YC17-1 SCANNER B1

SCANNER A2

SCANNER B2

SCANNER A1

YC17-2

YC17-3

YC17-4
