Kyocera FS-C8520MFP

To Next Page

To Previous Page

2MY/2MZ

1-2-6

9. Remove the tape.

Figure 1-2-7

10. Peel off two protective sheets.

11. Remove the spacer.

Figure 1-2-8

Tape

Spacer

Protective sheets
