Appendix-4 OPERATION GUIDE
The number of sheets that can be stored in the finisher and the specifications of stapling are shown below.
Names of Parts
1 Finisher tray
2 Process tray
3 Process tray extension
4 Finisher tray extension
5 Paper output guide 1
6 Paper output guide 2
NOTE: Sorted copies are output onto the finisher tray.
NOTE: According to the paper size, adjust the finisher
tray extension.
Tray capacity and paper sizes
Non-stapling 500 sheets (A4, 11 × 8
1/2", B5)
250 sheets (A3, B4, Folio, 11 × 17" (Ledger), 8
1/2 × 14" (Legal),
8 1/2 × 13" (Oficio II))
Stapling (80 g/m² or less) For stapling of 2 to 4 sheets: 130 sheets
For stapling of 5 sheets or more: 250 sheets
Stapling capacity 30 sheets (A4, 11 × 8 1/2", B5)
20 sheets (A3, B4, Folio, 11 × 17" (Ledger), 8
1/2 × 14" (Legal),
8 1/2 × 13" (Oficio II))
