97
can be found on page
69
.
“STOP”
flashes on the
display.
An emergency stop was
initiated by another manual
control.
Press the rotary knob to
cancel the emergency stop.
“OFF” flashes on the
display.
An emergency off was
initiated by another manual
control.
Press the rotary knob to
cancel the emergency off.
An amplifier has triggered
an emergency off due to a
short circuit or a power
overload.
Remove the short circuit.
In
case of a power overload
,
divide the layout into several
powe
r sections.
Read section
"The powe
r supply of a model
railway
layout
"
in the operating
manual of the LZV100
comm
and station or the LV102
amplifier.
