72 Operating manual LH101
or
b)
change to the binary display (and
changing the value)
or
c)
select another CV
or
d)
return to “Controlling locomotive”.
12.3.4.1 Binary (bitwise) displaying and changing of the CV value
There are two different ways of entering (or displaying) the desired
value in the CV: Decimal or bitwise (binary). You can choose your
preferred method. However, there are CVs for which bitwise entry is
easier; for other CVs decimal entry is the recommended.
Example:
In CV29, decoder settings are configured by setting or deleting bits.
Here, bitwise entry is recommended.
First, read out the content of the desired CV. Proceed as described in
the section "Reading out and programming a CV", page 71.
After the result is displayed, change
to the bitwise (binary) display of the
decimal numeric value.
The bottom line of the display
indicates which bits are set. For
decimal value 10 these are bits 2
and 4 (counting starts at 1).
If you want to make changes, press the corresponding number keys.
In the following example, bit 1 is to be set additionally while bit 2 is to
be deleted:
