Lenze 8400 motec User Manual

Firmware ≤ 02.00 - DMS 2.1 EN - 03/2011 L 217
8400 motec | Software Manual
Diagnostics & error management
Error messages of the operating system
PS31: Ident. error [xx.0144.00031]
dF01: Internal error 01 [xx.0145.00001]
dF02: Internal error 02 [xx.0145.00002]
dF03: Internal error 03 [xx.0145.00003]
dF04: Internal error 04 [xx.0145.00004]
Response (Lenze setting printed in bold)
 0: No Reaction : 1: Fault  2: Trouble  4: WarningLocked
Cause Remedy
Incompatible or unknown HW components have been
found.
• Check which HW components are faulty (C00203/x:
Product type code).
• Check connection between communication unit and
drive unit regarding for contact problems.
• Check temperature range of the device at the start.
• Replace communication unit.
• Check whether a software update at Lenze is possible.
Response (Lenze setting printed in bold)
 0: No Reaction : 1: Fault  2: Trouble  4: WarningLocked
Cause Remedy
Device error: No pulse width modulation • Reduce switching frequency (C00018) to 4 kHz.
• If the problem occurs again, you needs to consult
Lenze.
Response (Lenze setting printed in bold)
 0: No Reaction : 1: Fault  2: Trouble  4: WarningLocked
Cause Remedy
Device error • Mains switching or restart of the controller,
respectively.
• If the problem occurs again, you needs to consult
Lenze.
Response (Lenze setting printed in bold)
 0: No Reaction : 1: Fault  2: Trouble  4: WarningLocked
Cause Remedy
Device error • Mains switching or restart of the controller,
respectively.
• If the problem occurs again, you needs to consult
Lenze.
Response (Lenze setting printed in bold)
 0: No Reaction : 1: Fault  2: Trouble  4: WarningLocked
Cause Remedy
Device error • Mains switching or restart of the controller,
respectively.
• If the problem occurs again, you needs to consult
Lenze.

Lenze 8400 motec Specifications

General

Input Voltage	3-phase 380V to 480V AC
Control Mode	Vector control
Communication	CANopen, PROFIBUS, Ethernet
Protection Features	Overcurrent, overvoltage, undervoltage, short-circuit, overtemperature
Relative Humidity	≤ 95 %, no condensation
Altitude	Up to 1000m above sea level
Storage Temperature	-20°C to 65°C
