Lenze 8400 motec User Manual

Firmware ≤ 02.00 - DMS 2.1 EN - 03/2011 L 235
8400 motec | Software Manual
Parameter reference
Parameter list | C00003
C00003
C00005
C00006
Parameter | Name:
C00003 | Status of last device command
Data type: UNSIGNED_8
Index: 24572
d
= 5FFC
h
Status of the device command carried out last (C00002).
Note:
Before switching off the supply voltage after carrying out a device command, check whether the device command
has been carried out successfully via the status display!
Drive control (DCTRL)
: Device commands
Selection list (read only) Info
0 Successful Device command has been carried out successfully.
1 Command unknown Device command is implausible or not known in the
system.
2 No access Access for requested device command is not approved.
3 Time-out Device command could not be processed in the defined
time (time-out).
; Read access  Write access  CINH  PLC STOP ; No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00005 | Application
Data type: UNSIGNED_16
Index: 24570
d
= 5FFA
h
Drive application
Selection list (Lenze setting printed in bold) Info
1000 Actuating drive speed This technology application is used to solve speed-
controlled drive tasks, e.g. conveying belts.
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00006 | Motor control
Data type: UNSIGNED_8
Index: 24569
d
= 5FF9
h
Selection of the motor control mode
Motor control (MCTRL)
: Select control mode
Selection list (Lenze setting printed in bold) Info
4 SLVC: Vector control This control type is used for sensorless vector control of
an asynchronous motor.
• The control type requires motor parameters to be set
as exactly as possible!
Sensorless vector control
6 VFCplus: V/f linear This control type is used for the speed control of an
asynchronous motor via a linear V/f characteristic and is
the simplest control type.
• For setting the V/f characteristic, only the rated
frequency (C00089
) and the rated voltage (C00090) of
the motor have to be entered.
V/f characteristic control
7 VFCplus: V/f linear +encoder From version 02.00.00
This control type is used for speed control of an
asynchronous motor via a linear V/f characteristic.
• This control type requires a speed feedback via an
encoder connected to the motor!
• For setting the V/f characteristic, only the rated
frequency (C00089
) and the rated voltage (C00090) of
the motor have to be entered.
V/f control

Lenze 8400 motec Specifications

General

Input Voltage	3-phase 380V to 480V AC
Control Mode	Vector control
Communication	CANopen, PROFIBUS, Ethernet
Protection Features	Overcurrent, overvoltage, undervoltage, short-circuit, overtemperature
Relative Humidity	≤ 95 %, no condensation
Altitude	Up to 1000m above sea level
Storage Temperature	-20°C to 65°C
