Firmware ≤ 02.00 - DMS 2.1 EN - 03/2011 L 297
8400 motec | Software Manual
Parameter reference
Parameter list | C01911
C01911
Parameter | Name:
C01911 | DIP1 switches
Data type: UNSIGNED_8
Index: 22664
d
= 5888
h
Bit coded display of the DIP1 switch setting
Note:
• Settings made by DIP1, DIP2, P1, P2 and P3 must be activated with the DIP1/switch 1. The settings are accepted
anew every time the mains is switched on. As a consequence, interim changes of parameters may be
overwritten.
• Information on how to commission the 8400 motec via the DIP switches/potentiometers can be found in the
mounting instructions!
Display area (min. hex value | max. hex value)
0x00 0xFF
Value is bit-coded: Info
Bit 0 DIP1/1: DIP switch activated "1" ≡ Settings according to DIP1, DIP2, P1, P2 and P3 are
active.
• C00012
and C00013 (acceleration/deceleration time)
are overwritten with the setting of potentiometer P3.
• C00039/1
(fixed setpoint 1) is overwritten with the
setting of potentiometer P2.
Bit 1 DIP1/2: Direction of rotation
inverted
C00701/5 (bSetSpeedCcw) is overwritten:
"0" ≡ bSetSpeedCcw = unchanged
"1" ≡ bSetSpeedCcw = TRUE (Ccw active)
Bit 2 DIP1/3: V/f setting C00006 will be overwritten:
"0" ≡ V/f linear
"1" ≡ V/f square-law
Bit 3 DIP1/4: Flying restart process
activated
C00990 will be overwritten:
"0" ≡ Flying restart process deactivated
"1" ≡ Flying restart process activated
Bit 4 DIP1/5: Reserved
Bit 5 DIP1/6: Reserved
Bit 6 DIP1/7: Reserved
Bit 7 DIP1/8: relay configuration; DO1 C00621/1 and C00621/2 are overwritten:
"0" ≡ DO1=DriveReady / relay=DriveFail
"1" ≡ DO1=DriveFail / relay=DriveReady
; Read access Write access CINH PLC STOP ; No transfer COM MOT
