Lenze 8400 motec User Manual

8400 motec | Software Manual
Parameter reference
Parameter list | C00567
274 L Firmware ≤ 02.00 - DMS 2.1 EN - 03/2011
C00567
C00572
C00574
C00579
Parameter | Name:
C00567 | Resp. to lim. speed controller
Data type: UNSIGNED_8
Index: 24008
d
= 5DC8
h
From version 02.00.00
Response when the speed controller output is limited (bLimSpeedCtrlOut =TRUE)
Selection list (Lenze setting printed in bold)
0No Reaction
1Fault
4 WarningLocked
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00572 | Limit brake resistor overload
Data type: UNSIGNED_8
Index: 24003
d
= 5DC3
h
Adjustable threshold for monitoring the brake resistor utilisation
• The response for reaching the threshold can be selected in C00574
.
Setting range (min. value | unit | max. value) Lenze setting
0 % 100 100 %
; Read access ; Write access  CINH  PLC STOP  No transfer  COM ; MOT Scaling factor: 1
Parameter | Name:
C00574 | Resp. to overtemp. brake resistance
Data type: UNSIGNED_8
Index: 24001
d
= 5DC1
h
Response when reaching the threshold for the brake resistor utilisation set in C00572.
Selection list (Lenze setting printed in bold)
0 No Reaction
1Fault
4 WarningLocked
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00579 | Resp. to speed monitoring
Data type: UNSIGNED_8
Index: 23996
d
= 5DBC
h
Response when the max. speed limit (C00909) or output frequency limit (C00910) has been reached.
Selection list (Lenze setting printed in bold)
0No Reaction
1Fault
4 WarningLocked
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1

Lenze 8400 motec Specifications

General

Input Voltage	3-phase 380V to 480V AC
Control Mode	Vector control
Communication	CANopen, PROFIBUS, Ethernet
Protection Features	Overcurrent, overvoltage, undervoltage, short-circuit, overtemperature
Relative Humidity	≤ 95 %, no condensation
Altitude	Up to 1000m above sea level
Storage Temperature	-20°C to 65°C
