Lenze 8400 motec User Manual

Firmware ≤ 02.00 - DMS 2.1 EN - 03/2011 L 293
8400 motec | Software Manual
Parameter reference
Parameter list | C00990
C00990
C00991
C00992
C00994
C01082
Parameter | Name:
C00990 | Flying restart fct.: Activation
Data type: UNSIGNED_8
Index: 23585
d
= 5C21
h
Switch on /activate flying restart circuit for non-feedback drive systems
Flying restart function
Selection list (Lenze setting printed in bold)
0Off
1On
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00991 | Flying restart fct.: Process
Data type: UNSIGNED_16
Index: 23584
d
= 5C20
h
Selection of the speed search range for the flying restart function
Flying restart function
Selection list (Lenze setting printed in bold)
5 -n...+n | Last output frequency
6 -n...+n | Actual setpoint frequency
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00992 | Flying restart: Start frequency
Data type: INTEGER_16
Index: 23583
d
= 5C1F
h
Selection of the starting value for the flying restart function
Flying restart function
Setting range (min. value | unit | max. value) Lenze setting
-200 Hz 200 10 Hz
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00994 - Flying restart fct.: Current
Data type: INTEGER_16
Index: 23581
d
= 5C1D
h
Current to be injected during the flying restart process
•100% ≡ rated motor current (C00081
).
• The flying restart current should amount to 10 ... 25 % of the rated motor current.
Flying restart function
Setting range (min. value | unit | max. value) Lenze setting
0.0 % 100.0 25.0 %
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C01082 | LS_WriteParamList: Execute Mode
Data type: UNSIGNED_8
Index: 23493
d
= 5BC5
h
Parameter change-over: Selection of the activation method
Selection list (Lenze setting printed in bold) Info
0by Execute The writing of the parameter list is activated by a FALSE/
TRUE edge at the bExecute input.
1 by Input Select The parameter list is written if a change is made at the
bSelectWriteValue_1 selection input and once when the
controller is initialised.
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1

Lenze 8400 motec Specifications

General

Input Voltage	3-phase 380V to 480V AC
Control Mode	Vector control
Communication	CANopen, PROFIBUS, Ethernet
Protection Features	Overcurrent, overvoltage, undervoltage, short-circuit, overtemperature
Relative Humidity	≤ 95 %, no condensation
Altitude	Up to 1000m above sea level
Storage Temperature	-20°C to 65°C
