Lenze 8400 motec User Manual

8400 motec | Software Manual
Parameter reference
Parameter list | C00680
282 L Firmware ≤ 02.00 - DMS 2.1 EN - 03/2011
C00680
C00681
C00682
C00700
Parameter | Name:
C00680 | L_Compare_1: Fct.
Data type: UNSIGNED_8
Index: 23895
d
= 5D57
h
FB L_Compare_1: Comparison function
• If the statement of the selected comparison operation is true, the binary output bOut is set to TRUE.
Selection list (Lenze setting printed in bold)
1In1 = In2
2In1 > In2
3In1 < In2
4 |In1| = |In2|
5 |In1| > |In2|
6 |In1| < |In2|
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00681 | L_Compare_1: Hysteresis
Data type: INTEGER_16
Index: 23894
d
= 5D56
h
FB L_Compare_1: Hysteresis for the comparison function selected in C00680
Setting range (min. value | unit | max. value) Lenze setting
0.0 % 100.0 0.5 %
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00682 | L_Compare_1: Window
Data type: INTEGER_16
Index: 23893
d
= 5D55
h
FB L_Compare_1: Window for the comparison function selected in C00680
Setting range (min. value | unit | max. value) Lenze setting
0.0 % 100.0 2.0 %
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00700 | LA_NCtrl: Analogue connection list
Data type: UNSIGNED_16
Index: 23875
d
= 5D43
h
Selection list
See selection list - analog signals
Subcodes Lenze setting Info
C00700/1 10: AIn1_Out LA_NCtrl
: nMainSetValue_a
C00700/2 22: nPar3_a LA_NCtrl
: nTorqueMotLim_a
C00700/3 22: nPar3_a LA_NCtrl: nTorqueGenLim_a
C00700/4 0: Not connected Reserved
C00700/5 6: C_wDriveCtrl LA_NCtrl
:Network(MCI/CAN)_wDriveControl
C00700/6 1: C_nPos100_a(100.0%) LA_NCtrl
: nPIDVpAdapt_a
C00700/7 0: Not connected LA_NCtrl
: nPIDActValue_a
C00700/8 1: C_nPos100_a(100.0%) LA_NCtrl
: nPIDInfluence_a
C00700/9 0: Not connected LA_NCtrl
: nPIDSetValue_a
C00700/10 0: Not connected Reserved
C00700/11 0: Not connected L_GP_Counter1
: wLdVal
C00700/12 0: Not connected L_GP_Counter1
: wCmpVal
C00700/13 0: Not connected L_GP_Compare1
: nIn1_a
C00700/14 0: Not connected L_GP_Compare1
: nIn2_a
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1

Lenze 8400 motec Specifications

General

Input Voltage	3-phase 380V to 480V AC
Control Mode	Vector control
Communication	CANopen, PROFIBUS, Ethernet
Protection Features	Overcurrent, overvoltage, undervoltage, short-circuit, overtemperature
Relative Humidity	≤ 95 %, no condensation
Altitude	Up to 1000m above sea level
Storage Temperature	-20°C to 65°C
