Lexmark MS510 - Page 284

Assembly 1: Covers
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 40X8520 1 1 Dust cover (250‑sheet tray)
“Dust cover removal” on page 257
1 40X8521 1 1 Dust cover (550‑sheet tray)
“Dust cover removal” on page 257
2 40X8054 1 1 Rear door and cover
(MS510dn and M1145)
“Rear door and cover removal” on
page 257
2 40X8270 1 1 Rear door and cover
(MS610dn, MS610de, M3150dn,
and M3150)
“Rear door and cover removal” on
page 257
2 41X0239 1 1 Rear door and cover
(MS610de and M3150)
“Rear door and cover removal” on
page 257
3 40X9651 1 1 Right cover
(MS610de and M3150)
“Right cover removal” on page 194
4 40X8087 1 1 Right cover
(MS610dn and M3150dn)
“Right cover removal” on page 194
4 40X8052 1 1 Right cover
(MS510dn and M1145)
“Right cover removal” on page 194
5 40X8305 1 1 250-sheet tray N/A
5 40X8086 1 1 550-sheet tray N/A
6 40X8056 1 1 Front access cover
(MS510dn, MS610dn, M1145,
and M3150dn)
“Front access cover removal” on
page 235
6 40X8268 1 1 Front access cover
(MS610de and M3150)
“Front access cover removal” on
page 235
7 40X9148 1 1 Cartridge plunger
“Cartridge plunger removal” on
page 211
8 40X9131 1 1 MPF assembly (100 sheets)
“MPF assembly removal” on page
227
9 40X8051 1 1 Nameplate
(MS510dn and M1145)
“Nameplate removals” on page 216
9 41X0005 1 1 Nameplate
(MS610dn and M3150dn)
“Nameplate removals” on page 216
9 40X8272 1 1 Nameplate
(MS610de and M3150)
“Nameplate removals” on page 216
4514-6xx
Parts catalog
284
