Lexmark MS510 - Page 285

Asm-index P/N Units/mach Units/FRU Description Removal procedure
10 40X8057 1 1 Control panel cover and buttons
(MS610de and M3150)
Note: Does not include the UICC.
“Control panel assembly removals” on
page 218
“UICC removals” on page 222
11 40X8068 1 1 Bezel
(MS610de and M3150)
“Bezel removals” on page 214
12 40X8060 1 1 Control panel cover and buttons
(MS510dn and M1145)
Note: Does not include the UICC.
“Control panel assembly removals” on
page 218
“UICC removals” on page 222
12 40X8061 1 1 Control panel cover and buttons
(MS610dn and M3150dn)
Note: Does not include the UICC.
“Control panel assembly removals” on
page 218
“UICC removals” on page 222
13 40X8066 1 1 Bezel
(MS510dn and M1145)
“Bezel removals” on page 214
13 40X8067 1 1 Bezel
(MS610dn and M3150dn)
“Bezel removals” on page 214
14 40X8053 1 1 Left cover (MS510dn and M1145)
“Left cover removal” on page 181
14 40X8269 1 1 Left cover
(MS610dn, MS610de, M3150dn,
and M3150)
“Left cover removal” on page 181
15 40X8055 1 1 Top cover (MS510dn and M1145)
“Top cover removal” on page 264
15 40X8271 1 1 Top cover
(MS610dn, MS610de, M3150dn,
and M3150)
“Top cover removal” on page 264
NS 40X8273 4 40 Rubber foot N/A
4514-6xx
Parts catalog
285
