Service Manual 103
Dimensional Drawings
5. Dimensional Drawings
(unit: mm)
CRNN076SU*0
CRNN096SU*0
CRNN126SU*0
Installation plate
D
H
W
Model No. W H D
CRNN076SU*0
CRNN096SU*0 1030 290 153
CRNN126SU*0
