LG Multi V CRUN Series User Manual

78 Indoor Unit
Indoor Unit
Wall Mounted
Specifications
1. Specifications
Notes:-
1. Capacities are based on the following conditions:
Cooling: - Indoor Temperature 27°C(80.6°F) DB /19°C(66.2°F) WB z
- Outdoor Temperature 35°C(95°F) DB /24°C(75.2°F) WB
- Interconnecting Piping Length 7.5m
- Level Difference of Zero.
Heating: - Indoor Temperature 20°C(68°F) DB / 15°C(59°F) WB
- Outdoor Temperature 7°C(44.6°F) DB / 6°C(42.8°F) WB
- Interconnecting Piping Length 7.5 m
- Level Difference of Zero.
2. Capacities are Net Capacities.
3. Due to our policy of innovation some specifications may be changed without notification.
4. L.E.V. : Linear Expansion Valve
Conversion Formula
kcal/h = kW x 860
Btu/h = kW x 3414
cfm = m
3
/min x 35.3
Model Unit
W
Cooling Capacity kcal/h
Btu/h
W
Heating Capacity kcal/h
Btu/h
Dimensions (W*H*D)
mm
inch
Color
Coil Rows x Columns x FPI
Face Area m
2
Moisture removal l/h.
Type
Fan
Motor Output x Number W
Air Flow Rate(High) cmm
cfm
Drive
Speed control
Temperature Control
Sound Absorbing Thermal Insulation Material
Air Filter
Safety Device
Liquid Side mm(inch)
Pipe Connections Gas Side mm(inch)
Drain Pipe(Internal Dia.) mm
Net Weight kg(lbs)
Noise Level (Sound Press,1m, H/M/L) dBA±3
Power Supply Ø,V,Hz
Power Cable AWG#:P*mm
2
Refrigerant Control
Standard Accessories
CRNN076SRA0 CRNN096SRA0 CRNN126SRA0 CRNN186STA0
2,100 2,600 3,500 5,300
1,806 2,235 3,009 4,557
7,165 8,871 11,942 18,084
2,363 2,925 3,938 5,963
2,031 2,515 3,385 5,127
8,061 9,980 13,435 20,345
900*285*156 900*285*156 900*285*156 1090*314*172
35.4*11.2*6.1 35.4*11.2*6.1 35.4*11.2*6.1 42.9*12.4*6.8
White White White White
2*12*20 2*12*20 2*12*20 2*13*20
0.13 0.13 0.13 0.14
1.0 1.0 1.2 2.2
Cross Flow Fan Cross Flow Fan Cross Flow Fan Cross Flow Fan
7.5 7.5 14.4 22
5.6 7.0 9.5 13.5
196 247 336 477
Direct
Phase control
Microprocessor, Thermostat for cooling and heating
Foamed polystyrene
Resin Net(Washable)
Fuse Fuse Fuse Fuse
6.35 (1/4) 6.35 (1/4) 6.35 (1/4) 9.52(3/8)
12.7 (1/2) 12.7 (1/2) 12.7 (1/2) 15.88 (5/8)
25 25 25 25
7(15.4) 7(15.4) 8(17.6) 12(26.5)
30/33/27 34/31/28 36/33/30 40/37/34
1,220~240,50 1,220~240,50 1,220~240,50 1,220~240,50
12:3*2.5 12:3*2.5 12:3*2.5 12:3*2.5
L.E.V L.E.V L.E.V L.E.V
Operation Manual, Installation Manual, Installation Panel, Paper Pattern for
Installation, Clamps, Screws
