8. Replacement Parts List
Service Manual 19
Replacement Parts List
PART No.
CRNN076TCA0 CRNN096TCA0 CRNN126TCA0
130911 CABINET ASSEMBLY,INDOOR 3091A10024A R
146811 MOTOR ASSEMBLY,STEP 4681AR2727G R
152312 FILTER ASSEMBLY,AIR CLEANER 5231A10003A R
158580 PUMP ASSEMBLY,WATER 5859A10001A R
137211
PANEL ASSEMBLY,FRONT(INDOOR)
3721A10023Y R
249951
CONTROL BOX ASSEMBLY,INDOOR
4995A10024Q 4995A10024R 4995A10024X R
263230-1 THERMISTOR ASSEMBLY(ROOM) 6323AQ3214P R
263230-2 THERMISTOR ASSEMBLY(PIPE-IN) 6323AQ3226E R
263230-3
THERMISTOR ASSEMBLY(PIPE-OUT)
6323AQ3226V R
266012 SWITCH ASSEMBLY,FLOAT 6601A20001E R
267110
REMOTE CONTROLLER ASSEMBLY
6711A10002A R
268712 PWB(PCB) ASSEMBLY,DISPLAY 6871A20096B R
268714 PWB(PCB) ASSEMBLY,MAIN 6871A10089A 6871A10089B 6871A10089C R
330870 DRAIN PAN ASSEMBLY 3087A10005A R
346810 MOTOR ASSEMBLY,AC 4681A20003V R
352115 TUBE ASSEMBLY,EVAPORATOR IN 5211A10303A R
352116
TUBE ASSEMBLY,EVAPORATOR OUT
5211A20230D R
354210 EVAPORATOR ASSEMBLY,FIRST 5421A10011B 5421A10011A 5421A10011A R
359011 FAN ASSY,CROSS FLOW 5901AR2441A R
435310 GRILLE ASSEMBLY,INLET 3531A10062D R
W0CZZ CAPACITOR,DRAWING 3H00671E R
352150-1 DRAIN TUBE ASSEMBLY 5251AP2984A R
352150-2 DRAIN ASSEMBLY,TUBE 5251A20001A R
LOCATION No.
DESCRIPTION
REMARK
