Specifications
1. Specifications
Notes:-
1. Capacities are based on the following conditions:
Cooling: - Indoor Temperature 27°C(80.6°F) DB /19°C(66.2°F) WB
- Outdoor Temperature 35°C(95°F) DB /24°C(75.2°F) WB
- Interconnecting Piping Length 7.5m
- Level Difference of Zero.
Heating: - Indoor Temperature 20°C(68°F) DB / 15°C(59°F) WB
- Outdoor Temperature 7°C(44.6°F) DB / 6°C(42.8°F) WB
- Interconnecting Piping Length 7.5 m
- Level Difference of Zero.
2. Capacities are Net Capacities.
3. Due to our policy of innovation some specifications may be changed without notification.
4. L.E.V. : Linear Expansion Valve
Conversion Formula
kcal/h = kW x 860
Btu/h = kW x 3414
cfm = m
3
/min x 35.3
Model Unit
W
Cooling Capacity kcal/h
Btu/h
W
Heating Capacity kcal/h
Btu/h
Color
Dimensions (W*H*D)
mm
inch
Casing
Coil
Rows x Columns x FPI
Face Area
m
2
Moisture removal l/h.
Type
Motor Output x Number
W
Fan Air Flow Rate(High) cmm
cfm
Drive
Speed control
Temperature Control
Sound Absorbing Thermal Insulation Material
Safety Device
Liquid Side mm(inch)
Pipe Connections
Gas Side mm(inch)
Drain Pipe(Internal Dia.)
mm
Net Weight kg(lbs)
Noise Level
(Sound Press,1.5m, H/M/L)
dBA±3
Power Supply Ø,V,Hz
Power Cable
AWG#:P*mm
2
Refrigerant Control
Standard Accessories
CRNN186VBA0 CRNN246VBA0
5,300 7,032
4,557 6,048
18,084 24,600
5,963 7,735
5,127 6,653
20,345 26,400
White
1200*615*205
47.24*24.21*8.07
Galvanized Steel plate + Painting
2*12*18 2*12*18
0.26 0.26
2.5 3.0
Cross Flow Fan
30 30
13.5 16
477 565
Direct
Phase control
Microprocessor, Thermostat for cooling and heating
Foamed polystyrene
Fuse, Thermal Fuse for Fan Motor
9.52 (3/8)
15.88 (5/8)
17
30(66.1)
43 / 40 / 37 45/42/39
1,220~240,50
12:3*2.5
L.E.V
Owner Manual, Installation Manual, Paper Pattern for Installation, Drain
Hose, Clamp Metal, Insulation for Fitting, Clamps, Washers, Flare Nut.
