Replacement Parts List

10. Replacement Parts List

130911 CABINET ASSEMBLY,INDOOR 3091AP2533A R

132100 FRAME 3022AP1283B R

135303 GRILLE,INLET 5236AP1236A R

135314 GRILLE ASSEMBLY,INLET SUB 5237AP2817B R

135316 GRILLE ASSEMBLY,DIFFUSER(INDOOR) 3531A10272B R

137211 PANEL ASSEMBLY,FRONT(INDOOR) 3720AP2767P R

146811 MOTOR ASSEMBLY,STEP 4681AR2727G R

152302 FILTER(MECH),A/C 5230AP7093A R

159901 VANE ASSY 5991AP7334C R

159911 VANE ASSY,HORIZONTAL 5991AP2867B R

166000 SWITCH,PUSH 6600AP2059B R

235450 DISPLAY ASSEMBLY (MECH) 3545AP7224B R

237900 WINDOW,DISPLAY 3790AP7080A R

249951 CONTROL BOX ASSEMBLY,INDOOR 4995A10107A 4995A10107D R

263230-1 THERMISTOR ASSEMBLY(ROOM) 6323AQ3214E R

263230-2 THERMISTOR ASSEMBLY(PIPE-IN) 6323A30002C R

263230-3 THERMISTOR ASSEMBLY(PIPE-OUT) 6323AQ3226Y R

267110 REMOTE CONTROLLER ASSEMBLY 6711A10002A R

268712 PWB(PCB) ASSY,DISPLAY 6871AQ3263A R

268714 PWB(PCB) ASSEMBLY,MAIN 6871A10089M 6871A10089R R

330870 DRAIN PAN ASSEMBLY 3087AP7233A R

342800 BEARING 3H02821B R

346810 MOTOR ASSEMBLY,INDOOR 4681AP2306M 4681AP2306N R

352115 TUBE ASSEMBLY,EVAPORATOR IN 5211A10332A R

35211A TUBE ASSEMBLY,SUCTION INDOOR 5211AP2813E 5211AP2813J R

352150 HOSE ASSY,DRAIN 5251AP2460B R

354210 EVAPORATOR ASSEMBLY,FIRST 5421AP2812B 5421AP2812A R

359010 FAN ASSY,CROSS FLOW 5901AR2351E R

733010 PLATE ASSEMBLY,INSTALL(R) 3301AP7519A R

733010 PLATE ASSEMBLY,INSTALL(L) 3301AP7519B R

W0CZZ CAPACITOR, DRAWING 3H00671A R

CRNN186VBA0 CRNN246VBA0

LOCATION No.

DESCRIPTION

PART NO.

REMARKS
