LG Multi V CRUN Series User Manual

Service Manual 37
Specifications
1. Specifi cations
Notes:-
1. Capacities are based on the following conditions:
Cooling: - Indoor Temperature 27°C(80.6°F) DB /19°C(66.2°F) WB
- Outdoor Temperature 35°C(95°F) DB /24°C(75.2°F) WB
- Interconnecting Piping Length 7.5m
- Level Difference of Zero.
Heating: - Indoor Temperature 20°C(68°F) DB / 15°C(59°F) WB
- Outdoor Temperature 7°C(44.6°F) DB / 6°C(42.8°F) WB
- Interconnecting Piping Length 7.5 m
- Level Difference of Zero.
2. Capacities are Net Capacities.
3. Due to our policy of innovation some specifications may be changed without notification.
4. L.E.V. : Linear Expansion Valve
Conversion Formula
kcal/h = kW x 860
Btu/h = kW x 3414
cfm = m
3
/min x 35.3
Model Unit
W
Cooling Capacity kcal/h
Btu/h
W
Heating Capacity kcal/h
Btu/h
Casing
Dimensions (W*H*D)
mm
inch
Coil Rows x Columns x FPI
Face Area m
2
Moisture removal l/h.
Type
Fan
Motor Output x Number
W
Air Flow Rate(H/M/L) cmm
cfm
External Static Pressure
Pa
Drive
Speed control
Temperature Control
Sound Absorbing Thermal Insulation Material
Safety Device
Liquid Side mm(inch)
Pipe Connections
Gas Side mm(inch)
Drain Pipe(Internal Dia.)
mm
Net Weight kg(lbs)
Noise Level (Sound Press,1.5m, H/M/L) dBA±3
Power Supply Ø,V,Hz
Power Cable AWG#:P*mm
2
Refrigerant Control
Standard Accessories
CRNN186BHA0 CRNN246BHA0 CRNN286BGA0
5,300 7,000 8,200
4,557 6,019 7,052
18,084 23,885 27,995
5,963 7,875 9.255
5,127 6,771 7,933
20,345 26,870 31,494
Galvanized Steel Plate
880*260*450 880*260*450 1,180*298*450
34.6*10.2*17.7 34.6*10.2*17.7 46.4*11.7*17.7
2*10*21 3*10*21 3*12*21
0.15 0.15 0.20
2.0 2.5 3.0
Sirocco Fan Sirocco Fan Sirocco Fan
118 118 272
16.5 / 14.5 / 13 18 / 16.5 / 14 30 / 27 / 25
583 / 512 / 459 636 / 583 / 494 1,059 / 953 / 882
78.5 58.8 78.5
Direct
Phase control
Microprocessor, Thermostat for cooling and heating
Foamed polystyrene
Fuse, Thermal Fuse for Fan Motor
9.52 (3/8) 9.52 (3/8) 9.52 (3/8)
15.88 (5/8) 15.88 (5/8) 15.88 (5/8)
25 25 25
34(74.9) 35(77.2) 38(83.8)
36 / 34 / 32 38 / 35 / 32 40 / 38 / 36
1,220~240,50 1,220~240,50 1,220~240,50
12:3*2.5 12:3*2.5 12:3*2.5
L.E.V L.E.V L.E.V
Owner Manual, Installation Manual, Drain Hose, Clamp Metal, Insulation
for Fitting, Sealing Pads, Clamps, Screws
