138 Indoor Unit
Piping Diagrams
6. Piping Diagrams
Heat Exchanger
Turbo Fan
lndoor unit
LEV
:Heating
:Cooling
Filter
Filter
: Thermistor
Refrigerant pipe connection port diameter
[unit: mm(inch)]
Model
CRNN126SV*0
CRNN186SV*0
Gas
15.88(5/8)
Liquid
9.52(3/8)
