Service Manual 47
Replacement Parts List
8. Replacement Parts List
152302 FILTER(MECH),A/C 5230A30001M 5230A30001M R
152302 FILTER(MECH), A/C 5230A30001M R
158591 PUMP ASSEMBLY, WATER 5859A20002A R
249951 CONTROL BOX ASSEMBLY, INDOOR 4995A20164M 4995A20164L R
263230-1 THERMISTOR ASSEMBLY(ROOM) 6323AQ3214E R
263230-2 THERMISTOR ASSEMBLY(PIPE-IN) 6323AQ3226G R
263230-3 THERMISTOR ASSEMBLY(PIPE-OUT) 6323AQ3226W R
266012 SWITCH ASSEMBLY, FLOAT 6601A20001E R
267110 REMOTE CONTROLLER ASSEMBLY 6711A20043D R
268714 PWB(PCB) ASSEMBLY, MAIN 6871A10089J 6871A10089K R
330870 DRAIN PAN ASSEMBLY 3087A10008D R
336610-1 HOUSING(MECH), WRAPPER 3660A20017A R
336610-2 HOUSING(MECH), WRAPPER 3660A20018A R
346810 MOTOR ASEMBLY, INDOOR 4681A10013C R
352118 TUBE ASSEMBLY, MENIFOLD(INDOOR) 5211A20465D R
354210 EVAPORATOR ASSEMBLY, FIRST 5421A20100A 5421A20100B R
359012 FAN ASSEMBLY, BLOWER 5901A10026A R
352115 TUBE ASSEMBLY, EVAPORATOR IN 5211A10305B 5211A10305A R
W0CZZ CAPACITOR, DRAWING 2A00986D R
CRNN186BHA0 CRNN246BHA0
DESCRIPTION
LOCATION
No.
Part No.
REMARKS
152302 FILTER(MECH), A/C 5230A30001L R
158591 PUMP ASSEMBLY, WATER 5859A20002A R
249951 CONTROL BOX ASSEMBLY, INDOOR 4995A10127F 4995A10127G 4995A10127H R
263230-1 THERMISTOR ASSEMBLY(ROOM) 6323A30004D R
263230-2 THERMISTOR ASSEMBLY(PIPE-IN) 6323AQ3226G R
263230-3 THERMISTOR ASSEMBLY(PIPE-OUT) 6323AQ3226W R
266012 SWITCH ASSEMBLY, FLOAT 6601A20001E R
267110 REMOTE CONTROLLER ASSEMBLY 6711A20043D R
268714 PWB(PCB) ASSEMBLY, MAIN 6871A10089U 6871A10089L 6871A10089V R
330870 DRAIN PAN ASSEMBLY 3087A10008C R
336610-1 HOUSING(MECH), WRAPPER 3660A20019A R
336610-2 HOUSING(MECH), WRAPPER 3660A20020A R
346810 MOTOR ASEMBLY, INDOOR 4681A10013A R
352118 TUBE ASSEMBLY, MENIFOLD(INDOOR) 5211A20416G 5211A20416H R
354210 EVAPORATOR ASSEMBLY, FIRST 5421A10027C R
359012 FAN ASSEMBLY, BLOWER 5901A10026A R
55211G TUBE ASSEMBLY, EXPANSION 5211A10426A R
W0CZZ CAPACITOR, DRAWING 2A00986D R
CRNN286BGA0 CRNN366BGA0 CRNN426BGA0
DESCRIPTION
Part No.
REMARKS
152302 FILTER(MECH), A/C 5230A30001A R
158591 PUMP ASSEMBLY, WATER 5859A10002A R
249951 CONTROL BOX ASSEMBLY, INDOOR 4995A10127J R
263230-1 THERMISTOR ASSEMBLY(ROOM) 6323A30004D R
263230-2 THERMISTOR ASSEMBLY(PIPE-IN) 6323AQ3226G R
263230-3 THERMISTOR ASSEMBLY(PIPE-OUT) 6323AQ3226W R
266012 SWITCH ASSEMBLY, FLOAT 6601A20001E R
267110 REMOTE CONTROLLER ASSEMBLY 6711A10002D R
268714 PWB(PCB) ASSEMBLY, MAIN 6871A10089W R
330870 DRAIN PAN ASSEMBLY 3087A20023A R
336610-1 HOUSING(MECH), WRAPPER 3661A20009E R
336610-2 HOUSING(MECH), WRAPPER 3661A20009F R
346810 MOTOR ASEMBLY, INDOOR 4681A20005K R
352118 TUBE ASSEMBLY, MENIFOLD(INDOOR) 5211A30076B R
354210 EVAPORATOR ASSEMBLY, FIRST 5421A20008A R
359012-1 FAN ASSEMBLY, BLOWER 5901A10015E R
359012-2 FAN ASSEMBLY, BLOWER 5901A10015F R
55211G TUBE ASSEMBLY, EXPANSION 5211A10416A R
W0CZZ CAPACITOR, DRAWING 0CZZA20001C R
35211C-1 TUBE ASSEMBLY,DISCHARGE(IN) 5211A30077A R
35211C-2 TUBE ASSEMBLY,DISCHARGE(OUT) 5211A30094B R
CRNN486BEA0
DESCRIPTION
Part No.
REMARKS
LOCATION
No.
LOCATION
No.
