Service Manual 121
Piping Diagrams
6. Piping Diagrams
Heat Exchanger
Turbo Fan
lndoor unit
LEV
:Heating
:Cooling
Filter
Filter
: Thermistor
Refrigerant pipe connection port diameter
Model
CRNN096SP*0
CRNN126SP*0
Gas
12.7(1/2)
Liquid
6.35(1/4)
[unit: mm(inch)]
