92 Indoor Unit
Indoor Unit
Wall Mounted
Replacement Parts List
9. Replacement Parts List
CRNN076SRA0 CRNN096SRA0 CRNN126SRA0
131410 CHASSIS ASSEMBLY 3141A20005E R
135311
GRILLE ASSEMBLY,DISCHARGE(INDOOR)
3531A10192E R
135312 GRILLE ASSEMBLY,FRONT(INDOOR) 3531A10118W R
135516 COVER ASSEMBLY,MOTOR 3551A20050A R
146811 MOTOR ASSEMBLY,STEP 4681A20055A R
152302 FILTER(MECH),A/C 5230A20014A R
159901 VANE,HORIZONTAL 5990A20007A R
249951 CONTROL BOX ASSEMBLY,INDOOR 4995A20274A 4995A20274B 4995A20274C R
263230-1
THERMISTOR ASSEMBLY(ROOM, PIPE-IN)
6323A20004M R
263230-2 THERMISTOR ASSEMBLY(PIPE-OUT) 6323AQ3226Z R
268712 PWB(PCB) ASSEMBLY,DISPLAY 6871A20227J R
268715 PWB(PCB) ASSEMBLY,MAIN(AC) 6871A20274A R
268716 PWB(PCB) ASSEMBLY,MAIN(DC) 6871A20275A 6871A20275B 6871A20275C R
342800 BEARING 4280A20004A R
35211B TUBE ASSEMBLY,TUBING 5211A10324A R
352150 HOSE ASSEMBLY,DRAIN 5251AR2575F R
354210 EVAPORATOR ASSEMBLY,FIRST 5421A20086A R
733010 PLATE 1H00843A R
W0CZZ CAPACITOR,DRAWING 3H01487A R
346810 MOTOR ASSEMBLY,INDOOR 4681A20048L R
267110 REMOTE CONTROLLER ASSEMBLY 6711A20010B R
135314 GRILLE ASSEMBLY,INLET SUB 3531A10117U R
352115 TUBE ASSEMBLY,EVAPORATOR IN 5211A10310A R
352116 TUBE ASSEMBLY,EVAPORATOR OUT 5211A20911A R
359011 FAN ASSEMBLY,CROSS FLOW 5901A20007A R
Location
No.
Description
Part No.
Remarks
CRNN186STA0
131410 CHASSIS ASSEMBLY 3141A10002A R
135311
GRILLE ASSEMBLY,DISCHARGE(INDOOR)
3531A10231Y R
135314 GRILLE ASSEMBLY,INLET SUB 3531A20107L R
135312 GRILLE ASSEMBLY,FRONT(INDOOR) 3531A20207H R
135516 COVER ASSEMBLY,MOTOR 3551A20099C R
146811 MOTOR ASSEMBLY,STEP 4681A20055A R
152302 FILTER(MECH),A/C 5230A20001A R
159901-1 VANE,HORIZONTAL 5990A20008A R
159901-2 VANE,HORIZONTAL 5990A20009A R
249951 CONTROL BOX ASSEMBLY,INDOOR 4995A20274R R
263230-1
THERMISTOR ASSEMBLY(ROOM, PIPE-IN)
6323A20004M R
263230-2 THERMISTOR ASSEMBLY(PIPE-OUT) 6323AQ3226Z R
267110 REMOTE CONTROLLER ASSEMBLY 6711A20010B R
268712 PWB(PCB) ASSEMBLY,DISPLAY 6871A20227M R
268715 PWB(PCB) ASSEMBLY,MAIN(AC) 6871A20274A R
268716 PWB(PCB) ASSEMBLY,MAIN(DC) 6871A20275D R
342800 BEARING 4280A20004A R
346810 MOTOR ASSEMBLY,INDOOR 4681A20003D R
352115 TUBE ASSEMBLY,EVAPORATOR IN 5211A14006A R
352116 TUBE ASSEMBLY,EVAPORATOR OUT 5211A30057D R
35211B TUBE ASSEMBLY,TUBING 5211A10324B R
352150 HOSE ASSEMBLY,DRAIN 5251AR2575F R
359011 FAN ASSEMBLY,CROSS FLOW 5901A20008A R
733010 PLATE ASSEMBLY,INSTALL 3301A10002A R
W0CZZ CAPACITOR,DRAWING 3H01487G R
354210 EVAPORATOR ASSEMBLY,FIRST 5421A20010D R
Location
No.
Description
Part No.
Remarks
