16 Indoor Unit
Piping Diarams
5. Piping Diagrams
: Thermistor
Heat Exchanger
C . F.F.
lndoor unit
LEV
Filter
Filter
:Heating
:Cooling
Refrigerant pipe connection port diameter
Model
CRNN076TCA0
CRNN096TCA0
CRNN126TCA0
Gas
12.7(1/2)
Liquid
6.35(1/4)
[unit: mm(inch)]
