Service Manual 143
Replacement Parts List
10. Replacement parts List
131410 CHASSIS ASSEMBLY 3141A20008A R
135311-1 GRILLE ASSEMBLY, DISCHARGE(INDOOR) 3531A20124B R
135311-2 GRILLE ASSEMBLY, DISCHARGE(INDOOR) 3531A20125B R
135316 GRILLE ASSEMBLY, FRONT(INDOOR) BLUE 3531A10289A R
WOOD 3531A10153V R
METAL 3531A10153Z R
135303-1 GRILLE, INLET BLUE 3530A10116B R
WOOD 3530A10116A R
METAL 3530A10116D R
135303-2 GRILLE, INLET BLUE 3530A10117B R
WOOD 3530A10117A R
METAL 3530A10117D R
135500-1 COVER 3550A20060A R
135500-2 COVER(RIGHT) 3550A20120B R
135500-3 COVER(LEFT) 3550A20121B R
140570 LOCKER ASSEMBLY 3H02857A R
146811-1 MOTOR ASSEMBLY, STEP 4681A20055A R
146811-2 MOTOR ASSEMBLY, STEP 4681A20055C R
147581 LOUVER, HORIZONTAL 4758A20033A R
147582 LOUVER, VERTICAL 4758A20034A R
152302 FILTER(MECH), A/C 5230A10006B R
237900 WINDOW, DISPLAY 3790A20035A R
249951 CONTROL BOX ASEMBLY, INDOOR 4995A10098J 4995A10098K R
263230-1 THERMISTOR ASSEMBLY(ROOM, PIPE-IN) 6323A20004J R
263230-2 THERMISTOR ASSEMBLY(PIPE-OUT) 6323AQ3226V R
267110 REMOTE CONTROLLER ASSEMBLY 6711A20039P R
268712 PWB(PCB) ASSEMBLY, DISPLAY 6871A20250A R
268714 PWB(PCB) ASSEMBLY, MAIN 6871A10088T 6871A10088U R
330870 DRAIN PAN ASSEMBLY 3087A20013A R
346810-1 MOTOR ASSEMBLY, INDOOR(R) 4681A20047C R
346810-2 MOTOR ASSEMBLY, INDOOR(L) 4681A20047D R
349490 ORIFICE ASSEMBLY 4949A20002A R
352115 TUBE ASSEMBLY, EVAPORATOR IN 5211A10423A R
352116 TUBE ASSEMBLY, EVAPORATOR OUT 5211A20301H R
35211B TUBE ASSEMBLY, TUBING 5211A10424A R
352150 HOSE ASSEMBLY, DRAIN 5251AR1222Q R
352380-1 AIR GUIDE(R) 5238A10009A R
352380-2 AIR GUIDE(L) 5238A10010A R
354210 EVAPORATOR ASSEMBLY, FIRST 5421A20104A R
359012-1 FAN, TURBO(L) 5900A00004A R
359012-2 FAN, TURBO(R) 5900A00005A R
668713 PWB(PCB) ASSEMBLY, SUB 6871A30029A R
LOCATION
DESCRIPTION
PART No .
REMARKS
No.
CRNN126SV*0 CRNN186SV*
0
To Next Page
