Service Manual 85
Dimiensional Drawings
4. Dimiensional Drawings
Installation plate
(Unit : mm)
D
H
W
Model No.
CRNN076SRA0
CRNN096SRA0
CRNN126SRA0
CRNN186STA0
900
1090
285
314
156
172
WHD
