LG Multi V CRUN Series

Service Manual 27
Dimensional Drawings
CRNN246TDA0, CRNN286TDA0, CRNN366TDA0
CRNN426TDA0, CRNN486TDA0
290
950
950
950
950
290
210.5
180
52
140
40
110
30
90 90
110
55
840
785
840
678
Unit:cm
Ceiling
Ceiling Board
Ceiling Board
30 or more
Above 250 330 or less
100 or more
50 or
more
50 or
more
30 or less
Floor
(unit:mm)
