Operation 4
Standard equipment
¾ Push joystick (2) forwards by at least 40%
and then move to the zero position.
Joystick is unlocked for approx. one second
and the display (3) lights up in the display unit.
NOTE
If the joystick is
not moved forwards within this
time period, it i
s locked again.
¾ Push the joystick (2) forwards.
Clamp opens.
Once the joystic
k has been released, it is
locked again wit
hin one second.
¾ Pull the joystick (2) backwards.
Clamp closes.
Version 2: Mechanically locked
NOTE
The joystick (single lever) is recognisable by
the somewhat wider design of the bellows.
Operating Instructions – 394 807 10 01 EN – 07/2011 63
