LNS QUICK SIX S2 - Safety Devices; Description; Layout of the Safety Elements on the Bar Feeder

8 CHAPTER 1: BASIC NOTIONS
MOVE S2
The MOVE S2 bar feeder has been designed with a focus on maximum safety during its handling and
complies with all EC requirements.
Safety covers and devices make access to the moving parts of the bar feeder impossible. Safety switches
keep the bar feeder from operating when these protections are open.
The design of the switches, as well as their insertion into the bar feeder, makes it practically impossible to
bypass them.
By pressing the emergency stop button located on the remote control, the functions of the bar feeder and
the lathe are immediately stopped.
LNS or its local representative, may not be held responsible for possible accidents or
property damage, whether caused directly or not, by any means whatsoever, if certain
safety devices have not been included.
A Emergency stop push button (remote control)
B Main access cover
SQ10 Safety switch of the retraction system
SQ11 Safety switch of the main access cover
SQ15
Safety switch of the safety grid
SQ16 Safety switch of the chain loader (optical cell)
