44 CHAPTER 4: OPERATION
MOVE S2
During the loading cycle, the bar is automatically
loaded and positioned into the spindle, outside the
clamping device of the lathe (chuck or actuator).
This positioning corresponds to a value (Z)
programmed by the operator, which is equal to the
distance between the measuring cell and the position of
the material in the lathe clamping device.
With this system, the setting is the same for any bar
length.
Before handling the bar feeder, stop the lathe at the end of part cycle.
To modify these parameters, the bar feeder must be in
mode.
To validate a parameter or a value, hold the key corresponding to [
] until the icon
disappears.
Press the key [STOP].
Enter the main menu.
Enter the menu "positions/torques".
Go to the screen "top cut position".
